Product Details
- Place of Origin: xi'an china
- Brand Name: HY-FLEXO
- Model Number: HYTB-M
Multifunctional Coating Machine for Trial
Parameters:
| Substrate: | PET, PI, PE, copper foil, aluminum foil |
| Substrate width: | 300mm ~ 800mm |
| Coating method: | Micro-gravure, Comma, Slot die, Dual steel rollers coating |
| Max. speed: | 30m/min (Speed varies subject to different coating technology) |
| Unwind / Rewind dia.: | Unwind Φ500mm, Rewind Φ500mm |
| Unwind / Rewind method: | Disc type rotation frame with dual stations, Manual splicing |
| Heating method: | Guide roller type heating drier, Box low voltage UV solidifying, light of lamp can be adjusted |
| Optional: | Shaping, Dust eliminator, Corona treater, High voltage UV solidify at oven entrance and exit, Peeling rewind. |
